| Model | RCGF12-12-6 | RCGF16-16-6 | RCGF18-18-6 | RCGF24-24-8 | RCGF32-32-8 | RCGF40-40-10 |
| Production Capability(b/h)(500ml) | 3000 | 4000 | 5000 | 8000-10000 | 10000-12000 | 13000-15000 |
| Applicable Bottle Type | Bottle Diameter:Ø50- Ø100mm; Height:150-320mm; Volume:330-1500ml | |||||
| Applicable Cap Shape | Plastic Screw Cap | |||||
| Gas Source Pressure(MPa) | 0.6 | |||||
| Gas Consumption(m3/min) | 0.2 | 0.2 | 0.4 | 0.4 | 0.5 | 0.55 |
| Total Power(kw) | 4.6 | 4.6 | 5.4 | 6.4 | 8.07 | 9.56 |
| Total Weight(kg) | 2500 | 3200 | 3800 | 5200 | 6500 | 8000 |
| Dimension(L×W×H)(mm) | 2350×1700×2150 | 2600×1830×2030 | 2830×2030×2030 | 3220×2300×2600 | 3450×2510×2710 | 3800×2800×2710 |
